Products may vary from images.
Pressure compensated speed controls, with or without LVDT transducer. With or without on-board digital drivers.
| Image | Type / Mounting/ Format | Part Number | Description | Pressure (bar) | Max Flow (lpm) | Size | Datasheet | Quickstart | |
 |
Cetop subplate mounted | QVHZO-TEB | Direct, pressure compensated, on-board driver, LVDT transducer, fieldbus or IO-Link, smart tuning | 210 | 45 | 06 | FS412 | TK030 | QB300 |
|
Cetop subplate mounted | QVHZO-TES | Direct, pressure compensated, on-board driver, LVDT transducer, fieldbus or IO-Link, smart tuning | 210 | 45 | 06 | FS412 | TK030 | QF300 |
|
Cetop subplate mounted | QVKZOR-TEB | Direct, pressure compensated, on-board driver, LVDT transducer, fieldbus or IO-Link, smart tuning | 210 | 90 | 10 | FS412 | - | QB300 |
|
Cetop subplate mounted | QVKZOR-TES | Direct, pressure compensated, on-board driver, LVDT transducer, fieldbus or IO-Link, smart tuning | 210 | 90 | 10 | FS412 | - | QF300 |
 |
Cetop subplate mounted | QVHZO-T | Proportional flow, direct operated with transducer, 2/3 way pressure compensated, optional on board driver, optional fieldbus | 210 | 45 | 06 | F412 | TK030 | - |
| |
Cetop subplate mounted | QVKZOR-T | Proportional flow, direct operated with transducer, 2/3 way pressure compensated, optional on board driver, optional fieldbus | 210 | 90 | 10 | F412 | - | - |
 |
Cetop subplate mounted | QVHZO-A | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 45 | 06 | FS410 | TK030 | - |
| |
Cetop subplate mounted | QVHZO-AEB | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 45 | 06 | FS410 | TK030 | QB100 |
| |
Cetop subplate mounted | QVHZO-AES | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 45 | 06 | FS410 | TK030 | QF100 |
| |
Cetop subplate mounted | QVKZOR-A | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 90 | 10 | FS410 | - | - |
| |
Cetop subplate mounted | QVKZOR-AEB | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 90 | 10 | FS410 | - | QB100 |
| |
Cetop subplate mounted | QVKZOR-AES | Direct, pressure compensated, off-board or on-board driver, without transducer, fieldbus or IO-Link | 210 | 90 | 10 | FS410 | - | QF100 |
 |
Cetop subplate mounted | QVHZE-A | Direct, pressure compensated, off-board driver, without transducer | 210 | 45 | 06 | F400 | - | - |
| |
Cetop subplate mounted | QVKZE-A | Direct, pressure compensated, off-board driver, without transducer | 210 | 90 | 10 | F400 | - | - |
 |
Cetop subplate mounted | QVHMZO-A | Independent pressure and 3 way compensated flow control, direct, off-board driver, without transducer | 210 | 45 | 06 | TF490 | - | - |
| |
Cetop subplate mounted | QVKMZOR-A | Independent pressure and 3 way compensated flow control, direct, off-board driver, without transducer | 210 | 90 | 10 | TF490 | - | - |
