type | heading / type / mounting / format | part number | description | pressure (bar) | flow (lpm) | size | atos catalogue page |
---|---|---|---|---|---|---|---|
Cylinder | Mill type | CN | Cylinder, double acting, counterflanges, 40- 200mm bore | 250 | Variable | 40-200 mm | B180 |
Cylinder | Mill type | CC | Cylinder, double acting, counterflanges, 50- 320mm bore | 320 | Variable | 50-320 mm | B241 |
Cylinder | Mill type | CH | Cylinder, double acting, counterflanges, 250- 400mm bore | 250 | Variable | 250-400 mm | B160 |
Cylinder | Mill type | CNX | Cylinder, stainless steel, optional rod posiiton sensor, 50-100mm bore, 36-70mm rod, up to 3000m stroke | 150 | Variable | 50-100 mm | B180 |
