Hydrastore Dual Pressure Compensated Flow & Pressure Control Manifold

Ideal for various applications where pressure compensated speed control of an actuator in both directions is required. These controls offer meter in priority flow control with relief protection in both directions. Designed to accept a high input flow, the controls use a fixed orifice with compensator to limit the maximum priority flow supplied to the actuator regardless of load variations. Excess flow is returned to tank via the opposite service return line. A relief valve sensing on each priority output and relieving to the opposite service return line provides system relief protection. High performance check valves on each side of the circuit allow return flow from the actuator to pass back to tank with minimal loss.

Features

• Steel (zinc plated) or Aluminium (anodised) material options
• Fixed setting, no externally adjustable valves
• Compact, efficient design
• Up to 170 lpm inlet (120 lpm max. bypass)
